Safety instructions / Quick guide Thermo-6, water
HB-Therm®
Safety instructions and quick guide
Temperature control units Thermo-6 (water)
EN (Translation of original instructions)
General
Read these instructions carefully before starting any work. The basic prerequisites for working safely are compliance with all safety instructions and prudent action by qualified personnel in order to avoid accidents that lead to personal injury / property damage.
Safety instructions are marked with symbols:
Danger! / Warning! / Caution!
... indicates a hazardous situation which, if disregarded, may result in injury (Caution!) or serious or fatal injury (Warning!, Danger!).
Danger due to electric shock!
... if disregarded, there is a risk of serious or fatal injury.
Hot surface!
... if disregarded, there is a danger of mild to severe burns.
Attention!
... indicates a potentially hazardous situation which, if disregarded, may result in property damage.
Make sure that these instructions are accessible at all times in the immediate vicinity of the unit.
Further instruction information is available via the help system on the unit, and in detail via the «e-cockpit» app or http://knowledge.hb-therm.eu. If you have any questions or if anything is unclear, please contact your country representative (see type plate) or our customer service www.hb-therm.com.
Designation use
The temperature control unit is used to heat or cool a connected consumer (e.g. mould) to a specified temperature by means of a heat transfer medium (water) and to maintain this temperature. The unit is designed and constructed exclusively for the specified values in accordance with its type plate.
Claims of any kind due to improper use are excluded.
General safety instructions
Observe local, legal and company safety regulations and requirements.
Always wear the legally and operationally prescribed protective equipment for the respective work.
Operating materials can reach high temperatures and high pressures during operation and cause burns on contact.
Do not touch hot surfaces without protective gloves.
Regularly check the entire system for leaks or damage. Check the hose lines and screw connections for tightness. Remedy any defects immediately.
Always keep these instructions and all information on the unit clearly legible. Replace damaged or illegible information immediately.
Never override safety devices.
In the event of uncontrolled faults, set the main switch to the O position to trigger an emergency stop.
Disconnect the unit from the power supply when opening it. Secure the disconnection against switching on. Owing to charged capacitors, wait 5 minutes after switching off the power supply to work on the frequency converter.
Carry out the requested maintenance work. Maintenance work may only be carried out by qualified personnel.
Cool down, depressurise and switch off the unit before carrying out maintenance, repair or cleaning work. Check that it is pressure-free.
Maintenance work on the magnetic coupling of the pump is prohibited for people wearing a pacemaker.
Only use original spare parts from the manufacturer.
Transport and packaging
Check the delivery immediately on receipt for completeness and for any transport damage.
Transporting, crane and lifting equipment must be suitable and operated by qualified personnel.
For transportation purposes, the unit must be completely empty (cooling and system circuit).
For careful handling and in-plant transport, observe the symbols and instructions on the packaging.
To protect the unit, do not remove the packaging until shortly before installation.
When shipping a unit, use only the original or equivalent packaging. Only transport the unit upright.
Procedure for carrying by crane
- Pull out the lifting device at the rear of the unit.
- Attach lifting straps to the lifting device and to the front handle.
Installation
Electrical installation and initial commissioning must be carried out by qualified electricians.
Hydraulic installation and initial commissioning must be carried out by hydraulics specialists.
To protect the entire system, the guide values for water quality must be observed. Detailed information is available at http://knowledge.hb-therm.eu.
Remove the protective film from the display.
Installation conditions
| Unit location | water-protected indoor area |
| sufficiently good ventilation | |
| Max. installation altitude | 3000 m above sea level |
| Installation area | horizontal, stable and low-vibration surface |
| Permissible ambient temperature | 5–40 °C |
| Relative Humidity | 35–85 % RH (non-condensing) |
| Main switch and emergency stop | Access at any time |
| Secure units | Lock the brake on the front castors. Secure units on elevations to prevent them from falling. |
| External cables | Cables must not touch hydraulic lines or parts whose surface temperatures are above 50 °C. |
Connections
Use only suitable pressure- and temperature-resistant connections, screw connections and hose lines.
Use assembly pastes for all screw connections, as these tend to seize up (especially stainless steel on stainless steel).
The use of a type B residual current device (RCD) is recommended. A type A RCD is not suitable as the unit is equipped with a frequency converter. The leakage current is a maximum of 5 mA per unit.
The heating capacity is applicable to mains voltage (220 V, 400 V, 460 V) with internal heating capacity limitation, and it changes within the specified voltage range by a maximum of ±10 %.
| Main line, Return line | Thread | G3/4 |
| Resistance | pmax (see type plate), θ = 20 + θmax (see type plate) | |
| Cooling water, separate system water | Thread | Cooling A2: G3/8 (cooling water) Cooling B2: G1/2 (cooling water) G1/4 (separate system water) |
| Pressure | p = 2–5 bar | |
| Resistance | p = 10 bar, θ = 100 °C | |
| Compressed air (ZG) | Thread | G1/4 |
| Pressure | p = 2–8 bar | |
| Resistance | p = 10 bar, θ = 100 °C | |
| Electrical mains connection | Mains voltage U (see type plate) | |
| Maximum pre-fuse Imax (see type plate) | ||
Procedure
- Connect the cooling water inlet
and outlet
to the cooling water supply. - Connect the main line (OUT) and return line (IN) to the mould circuit.
- Optional connect the system water inlet (S1) and outlet (S2) to a separate system water supply.
- Connect the compressed air inlet (AIR IN) to the compressed air supply and the outlet (AIR OUT) to the pressure-free tank or discharge water outlet (ZG).
- Connect to the electrical mains.
- Connect the optional OPC UA data interface.
- Connect the optional HB data interface.
- Connect the optional external control (ZB).
- Connect the optional external sensor (ZE).
→ Press the menu button
→ press ʹSettingʹ → press ʹExternal sensorʹ → press ʹExternal sensor typeʹ and select type
Commissioning
When initially starting-up, all electrical connections must be checked.
Main switch and emergency stop
Before switch on again after an emergency stop, make sure that the cause of the emergency stop has been eliminated and that all safety devices are working.
As a rule, switch off the unit using the on/off button
and only in an emergency via the main switch.
The main switch switches the power supply in the unit to all poles and is also an emergency stop switch. In position I (mains ON), the unit initialisation starts and during the initial start-up, the setup assistent starts automatically. "Ready to operate" appears on the display.
After an emergency stop due to a hazardous situation, the following applies:
- Disconnect the unit from the power supply. Secure the disconnection against switching on.
- Follow local and company safety instructions and emergency procedures.
- It is essential to engage qualified personnel for troubleshooting and functional testing.
Switching On/Off
By pressing the On/Off button , the unit starts in the defined operating mode. If necessary, it is filled and vented.
The unit switches off by pressing the On/Off button again. If necessary, it is cooled, emptied and depressurised.
Changing the set temperature
The input keyboard is displayed by pressing 'Set temperature' on the basic screen. Enter the desired set value and confirm with Enter.
Go to Knowledge home page for general information
| Type of unit power cable | CE | H07RN-F/H07BQ-F | ||
| UL/CSA | SO/SOW/SOOW | |||
Cross-section | CE | UL/CSA | ||
| U = 400/460 V | 8 kW | 4x2,5 mm2 | 4xAWG 12 | |
| 16 kW | 4x6,0 mm2 | 4xAWG 10 | ||
| U = 220 V | 8 kW | 4x6,0 mm2 | 4xAWG 10 | |
| 16 kW | 4x16,0 mm2 | 4xAWG 4 | ||
| Rated short-circuit current | 6 kA | |||
| Power grid | TN (power grid with protective conductor) | |||
| Overvoltage category | II | |||
| Degree of contamination | 2 | |||
The type plate is located on the rear panel of the unit and on the inside of the door.
The following information can be taken from the type plate:
- Type
- Unit number
- Performance values
- Additional
- Connection values
- Year of manufacture
- Protection class
- Manufacturer
- Service point
